Coil Transfer Car
The coil trolley is designed to move large steel coils efficiently across factory floors. Featuring robust construction, it operates on installed rails and ensures quick, safe transport with a capacity of up to 20,000 kg. Made in Vietnam, it’s ideal for heavy-duty coil handling equipment.
- Efficient coil handling equipment for horizontal coil transport in factories.
- Moves coils at speeds of up to 8.2 meters per minute, ensuring high productivity.
- Supports up to 20,000 kg with coil diameter ranging from 1400mm to 2000mm.
- Coil transfer car operates on pre-installed rails, enhancing maneuverability and safety.
- Optimized for moving large steel coils, offering better efficiency and safety than traditional methods.
Overview
The coil transfer trolley is engineered to provide efficient and safe transportation of large steel coils in industrial environments. Powered by an electric hoist, this coil cart runs smoothly along fixed rails, reducing the need for manual lifting and minimizing the risk of damage. Perfect for steel mills and warehouses, it enhances workflow by speeding up the coil handling process.
Features:
- Coil lifter with a load capacity of up to 20,000 kg.
- High-speed operation at 8.2 meters per minute for fast coil transfer.
- Easy mobility thanks to operation along rail systems.
- Enhanced safety mechanisms to prevent coil slippage and damage.
- Compact design for efficient space usage and smooth operation.
Applications:
This coil transfer trolley is ideal for steel mills, warehouses, and factories where large coils need to be transported across vast distances. It is perfect for operations requiring the quick and safe movement of coils in industries such as steel, metalworking, and manufacturing.
Suitable materials:
- Steel coils (up to 20,000 kg)
- Aluminum coils
- Copper coils
Contact information:
For export inquiries, contact us at +84 909 073 505.
Technical Specifications
| NO. | SPECIFICATION | UNIT | VALUE |
|---|---|---|---|
| 1 | Motor for transporting sheet. | - | GH50-1500W140SB, i=140 |
| 2 | Maximum material weight on the vehicle. | Kg | 20000 |
| 3 | Maximum material width on the vehicle. | mm | 1500 |
| 4 | Material diameter on the vehicle. | mm | 1400 - 2000 |
| 5 | Vehicle movement speed. | m/min | 8.2 |
| 6 | Vehicle dimensions (LxWxH). | mm | 2140x1200x835 |
| 7 | Vehicle weight. | Kg | 1600 |
User Manual
